Asrock Z790 Pro RS Intel Z790 LGA 1700 ATX

Περιγραφή

Μητρική πλακέτα Z790 PRO RS της Z790 PRO RS.

• Υποστηρίζει επεξεργαστές Intel Core 13ης και 12ης γενιάς
• Σχεδιασμός ισχύος 14+1+1 φάσεων, Dr.MOS για VCore+GT
• 4 x DDR5 DIMM, υποστηρίζει έως και 6800+ (OC)
• 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key-E για Wi-Fi
• Επιλογές εξόδου γραφικών: 1 HDMI, 1 DisplayPort, eDP
• Ήχος HD 7.1 καναλιών (κωδικοποιητής ήχου Realtek ALC897), Nahimic Audio
• 4 Hyper M.2 (PCIe Gen4x4), 8 SATA3
• 1 USB 3.2 Gen2 Type-C (Μπροστά), 1 USB 3.2 Gen2 Type-C (Πίσω), 1 USB 3.2 Gen2 Type-A (Πίσω), 6 USB 3.2 Gen1 (2 Πίσω, 4 Μπροστά), 8 USB 2.0 (4 Πίσω, 4 Μπροστά)
• Realtek 2.5G LAN

Description Z790 PRO RS motherboard

• Supports 13th and 12th generation Intel Core processors
• 14+1+1 phase power design, Dr.MOS for VCore+GT
• 4 x DDR5 DIMM, supports up to 6800+(OC)
• 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key-E for Wi-Fi
• Graphics output options: 1 HDMI, 1 DisplayPort, eDP
• 7.1-channel HD audio (Realtek ALC897 audio codec), Nahimic Audio
• 4 Hyper M.2 (PCIe Gen4x4), 8 SATA3
• 1 USB 3.2 Gen2 Type-C (Front), 1 USB 3.2 Gen2 Type-C (Rear), 1 USB 3.2 Gen2 Type-A (Rear), 6 USB 3.2 Gen1 (2 Rear, 4 Front), 8 USB 2.0 (4 Rear, 4 Front)
• Realtek 2.5G LAN

Model Z790 Pro RS
21902
21522
637
586
Chipset type Intel Z790
4403
22020
23079
Max memory size 1
12362
19491
22890
11530
Max. number of SATA devices 8
635
Detailed data on disk/drive interfaces CPU:

• 1 x Hyper M.2 slot (M2_1, Key M), supports 2260/2280 PCIe Gen4x4 (64 Gbps) mode*.

Chipset:

• 1 x Hyper M.2 slot (M2_2, Key M), supports 2260/2280 PCIe Gen4x4 (64 Gbps) mode*.
• 1 x Hyper M.2 slot (M2_3, Key M), supports 2260/2280 PCIe Gen4x4 (64 Gb/s)* mode
• 1 x Hyper M.2 slot (M2_4, Key M), supports 2260/2280 PCIe Gen4x4 (64 Gb/s)* mode
• 8 x SATA3 6.0Gb/s connectors

*Supports Intel Volume Management Device (VMD) Supports NVMe SSD as bootable drives
Graphics

• Intel Xe graphics architecture (Gen 12)
• 1 x eDP 1.4, supports max. resolution up to Full HD 60Hz
• 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz
• 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz

*Intel UHD Graphics Built-in Visuals and VGA outputs can only be supported with GPU-integrated processors.
Sound card

• 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
• Nahimic Audio

18721
Network interface

• 2.5 Gigabit LAN 10/100/1000/2500 Mbps
• Dragon RTL8125BG
• Supports Dragon 2.5G LAN software
• Intelligent automatic bandwidth adjustment
• Visual user-friendly user interface
• Visual network usage statistics
• Optimised default settings for game, browser and streaming modes
• User customisable priority control

USB ports at back panel 8
USB ports on motherboard 1
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 3
646
389
391
5236
7788
5245
11653
11055
5247
5239
5241
5251
5237
5250
7475
7492
7486
12168
7474
7481
7500
19614
19599
7795
BIOS 128Mb AMI UEFI Legal BIOS with GUI support
648
Dimensions 30.5 x 24.4 cm
Accessories included

• 1 x user manual
• 2 x SATA data cables
• 5 x Screws for M.2 sockets
• 1 x Bracket for M.2 socket

9594
22012
Software Software

• ASRock Motherboard Utility (A-Tuning)
• ASRock Dragon 2.5G LAN Software
• ASRock Polychrome SYNC*

UEFI

• ASRock EZ Mode
• ASRock Full HD UEFI
• ASRock My Favorites in UEFI
• ASRock Auto Driver Installer
• ASRock Instant Flash
• ASRock Easy RAID Installer
