MSI Pro Z890-S WIFI Motherboard ATX με Intel 1851 Socket

Περιγραφή

PRO Z890-S WIFI
PRO Z890-S WIFI features a simple design with a harmonious silver color scheme that perfectly matches both white and black computers. It is designed with many exclusive MSI features, true Wi-Fi 7 with EZ Antenna, 2.5G LAN, Thunderbolt 4, PCIe 5.0 M.2 and additional PCIe power supply, ready for Intel Core Ultra processors.

• Intel Core Ultra (Series 2) processor support for LGA 1851 socket
• DDR5 memory support, dual-channel DDR5 8600+ MT/s (OC)
• Improved power design: 12+1+1+1 Duet Rail Power System with P-PAK, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB
• Frozr Guard: Extended heatsink, 7W/mK MOSFET thermal pads, additional choke thermal pads, and M.2 Frozr guard are built for high system performance and uninterrupted operation
• EZ DIY: EZ M.2 Clip II, EZ PCIe Clip II, and EZ Antenna
• Lightning fast gaming experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
• Thunderbolt 4: Brings Thunderbolt to USB-C at true 40Gbps speed, display support 8K, Daisy-Chain, Multi-Port Accessory Architecture and USB 4.0 Compatibility
• 2.5G LAN with Intel Wi-Fi 7 Solution: Enhanced networking solution for professional and multimedia use, providing a secure, stable and fast network
• Audio Enhancement: Reward your ears with studio-grade sound quality for the most immersive gaming experience

Description PRO Z890-S WIFIPRO Z890-S WIFI features a simple design with a harmonious silver color scheme that perfectly matches both white and black computers. It is designed with many exclusive MSI features, true Wi-Fi 7 with EZ Antenna, 2.5G LAN, Thunderbolt 4, PCIe 5.0 M.2 and additional PCIe power supply, ready for Intel Core Ultra processors.

• Intel Core Ultra (Series 2) processor support for LGA 1851 socket
• DDR5 memory support, dual-channel DDR5 8600+ MT/s (OC)
• Improved power design: 12+1+1+1 Duet Rail Power System with P-PAK, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB
• Frozr Guard: Extended heatsink, 7W/mK MOSFET thermal pads, additional choke thermal pads, and M.2 Frozr guard are built for high system performance and uninterrupted operation
• EZ DIY: EZ M.2 Clip II, EZ PCIe Clip II, and EZ Antenna
• Lightning fast gaming experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2
• Thunderbolt 4: Brings Thunderbolt to USB-C at true 40Gbps speed, display support 8K, Daisy-Chain, Multi-Port Accessory Architecture and USB 4.0 Compatibility
• 2.5G LAN with Intel Wi-Fi 7 Solution: Enhanced networking solution for professional and multimedia use, providing a secure, stable and fast network
• Audio Enhancement: Reward your ears with studio-grade sound quality for the most immersive gaming experience

Model PRO Z890-S WIFI
25175
24470
637
586
Chipset type  INTEL Z890
4403
22020
25302
23081
22643
19476
Max memory size 2
25395
12363
20070
22890
18363
Max. number of SATA devices 4
635
Detailed data on disk/drive interfaces

• 3x M.2
• M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices
• M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
• M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
• 4x SATA 6G
• *Please refer to the manual for M.2 SSD heatsink restrictions.
• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
• Supports RAID 0, RAID 1, RAID 5 for M.2 NVMe storage devices


Graphics

• 1x HDMI
• HDMI 2.1 support, max resolution 4K 60Hz*
• 1x DisplayPort
• DisplayPort 1.4 support, max resolution 4K 60Hz*
• 1x Type-C DisplayPort
• Thunderbolt 4 port, DisplayPort 2.1 support with UHBR20 over USB Type-C, max resolution 4K@120Hz / 8K@60Hz*
• *Only available with processors with integrated graphics. Graphics specifications may vary depending on the installed processor.

Sound card

• Realtek ALC897 Codec
• 7.1-Channel High Definition Audio


24058
18721
927
Network interface LAN

• Realtek 8125D 2.5Gbps LAN

Wireless LAN and Bluetooth

• Intel Wi-Fi 7
• Wireless module is pre-installed in M.2 (Key-E) slot
• Supports MU-MIMO TX/RX, 2.4GHz/5GHz/6GHz*(320MHz) up to 5.8Gbps
• Supports 802.11 a/b/g/n/ac/ax/be
• Supports Bluetooth 5.4**, MLO, 4KQAM

USB ports at back panel 8
USB ports on motherboard 8
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 8
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 4
646
389
391
5250
11653
5249
5237
5236
5239
5241
5251
23084
7491
7475
7795
7492
7487
7486
7474
12813
7500
19614
7793
19599
7494
23467
25422
23174
23202
648
Dimensions 243.84 mm x 304.8 mm
