PROART X870E-CREATOR WIFI

Περιγραφή

Λογότυπο ProArt X870E-CREATOR WIFI
Η μητρική πλακέτα ProArt X870E-Creator WiFi δίνει τη δυνατότητα στους δημιουργούς όλων των επιπέδων να μεγιστοποιήσουν την απόδοση των τελευταίων επεξεργαστών AMD Ryzen 9000, 8000 και 7000 σειρών με 16+2+2 power bank, υποδοχές DDR5, PCIe 5.0 και αστραπιαία συνδεσιμότητα, συμπεριλαμβανομένων διπλών USB4, 10G και 2.5G Ethernet και WiFi 7.

Αυτή η μητρική πλακέτα ενσαρκώνει ένα επαγγελματικό, κομψό και ακριβές όραμα για δημιουργούς περιεχομένου όλων των ειδών, με στυλ που αναβαθμίζεται από ένα μαύρο φινίρισμα σε απόχρωση με μεταλλικές χρυσές λεπτομέρειες. Το διαφανές κάλυμμα I/O παρέχει στους χρήστες μια κομψή ματιά στις premium υποδοχές στο εσωτερικό.

Description ProArt logo X870E-CREATOR WIFIThe ProArt X870E-Creator WiFi motherboard empowers creators of all levels to maximize the performance of the latest AMD Ryzen 9000, 8000 and 7000 series processors with 16+2+2 power banks, DDR5 slots, PCIe 5.0 and lightning-fast connectivity including dual USB4, 10G and 2.5G Ethernet and WiFi 7.This motherboard embodies a professional, elegant and precise vision for content creators of all kinds, with style elevated by a tone-on-tone black finish with metallic gold accents. The transparent I/O cover provides users with a stylish glimpse of the premium connectors inside.
Model PROART X870E-CREATOR WIFI
22862
17383
16025
15632
19464
637
587
Chipset type AMD X870E
4403
22020
23117
Max memory size 1
23039
19491
25010
Max. number of SATA devices 4
635
Detailed data on disk/drive interfaces Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors*M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)**AMD X870E ChipsetM.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)M.2_4 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)4 x SATA 6Gb/s ports*AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10. RAID 5 Function is only supported by AMD Ryzen 9000series CPU.** PCIEX16(G5)_2 slot shares bandwidth with M.2_2.
Graphics

• 1 x HDMITM port**
• 2 x USB4 (40Gbps) ports support USB Type-C display outputs***

* Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.** Supports 4K@60Hz as specified in HDMI 2.1.  *** Supports max. 8K@60Hz as specified in DisplayPort 1.4.**** Output at USB4_EC1 and USB4_EC2, each requires a USB-C to DisplayPort adapter cable. VGA resolution support depends on processors' or graphic cards' resolution.
Sound card Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC*

• Impedance detection for front and rear headphone outputs
• Internal audio amplifier to enhance the highest sound quality for headphones and speakers
• Supports: jack detection, streaming, front panel jack repurposing
• High quality stereo playback output SNR 120 dB and recording input SNR 113 dB (line in)
• Supports up to 32-bit/192 kHz playback*

Audio features

• Audio shielding
• Premium audio capacitors
• Dedicated PCB audio layers
• Unique de-pop circuit

* Due to HDA bandwidth limitations,32-bit/192 kHz is not supported for 7.1 surround sound.** A chassis with an HD audio module on the front panel is required to support 7.1 surround audio output.
24058
18721
642
927
Network interface Ethernet

• 1 x Marvell AQtion 10Gb Ethernet
• 1 x Intel 2.5Gb Ethernet
• ASUS LANGuard

Wireless & Bluetooth

• Wi-Fi 7*
• 2×2 Wi-Fi 7 (802.11be)
• Supports 2.4/5/6 GHz frequency band**
• Supports Wi-Fi 7 320 MHz band, up to 6.5 Gbps transfer speed.
• Bluetooth v5.4***

*Wi-Fi features may vary by OSFor Windows 11, Wi-Fi 7 will require version 24H2 or later for full functionality, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E.For Windows 10, please note that there is no driver available, please refer to the Wi-Fi chipset vendor's website for details.**6GHz Wi-Fi frequency band and bandwidth regulations may vary by country.***Bluetooth version may vary. Please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB ports at back panel 1
USB ports on motherboard 9
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 2
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 1
646
390
391
24369
5250
5236
7823
5253
5254
5255
5926
5924
11653
19580
7778
19601
7792
7790
7484
7487
19599
7474
20067
7794
7827
7494
7499
19614
7475
7486
7491
10609
10610
23202
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
648
Dimensions 30.5 cm x 24.4 cm
Accessories included

• DisplayPort Cable
• 4 x SATA 6Gb/s Cables
• Extra Cooling Kit
• Thermal Pad for M.2 22110
• Q-ASUS WiFi Antenna
• Q-Connector
• Q-Latch M.2 Pack
• Q-Latch Q-Slide M.2 Pack for M.2 Backplate
• 2 x Rubber Packs for M.2
• ProArt Ruler
• Quick Guide
• ACC Express Activation Key Card

22012
Software ASUS Exclusive SoftwareArmory Crate- Aura Creator- Aura Sync- Fan Xpert 4 with AI Cooling II- Power SavingASUS DriverHubASUS GlideXUSB Wattage WatcherTurboV CoreASUS CPU-ZProArt Creator HubCreationFirstAdobe Creative Cloud (Free Trial)Norton 360 Deluxe (60 Days Free Trial)WinRAR (40 Days Free Trial)UEFI BIOSASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ ModeFlexKey
