Router CUDY IR04_EU

Περιγραφή

IR04

26936
Model IR04
Description A cellular Wi-Fi router with mobile connectivity for networking in harsh conditions such as moving vehicles, manufacturing, maritime, oil & gas, and mining.12 Types of InterfacesVersatile interfaces meet the networking, control, and data acquisition needs of various devices. The interfaces include: Ethernet, USB, RS232, RS485, RS422, Ignition Sensing, Analog Input, DI-Dry, DI-Wet, DO-Dry, DO-Wet, and Wi-Fi.DC. 4-Pin. PoE. Passive PoE.Different power options enable flexible installation ideal for integration into machines, production lines, moving vehicles, and distribution boxes.

• DC
• 4-Pin Socket
• 802.3at/af PoE
• Passive PoE

Works in Heat, Cold, Shock, Vibration, EMC InterferenceBuilt with a sophisticated design and high-quality components, the device achieves Level 4 EMC. Its precisely crafted aluminum alloy body and integrated heat sink design enable it to withstand shock and vibration, operate in extreme temperatures, and ensure long-lasting durability.
3258
1217
24776
18769
3881
18864
11231
3950
8966
3982
3981
Power supply Power Adapter

• Input: 100-240V~, 50/60Hz
• Output: 12V1A

Max Power Consumption: 9.6W Power Methods:

• DC
• 802.3at/af PoE
• Passive PoE

Power Input:

• DC: 11-57V1A
• 4-Pin DC: 11-57V
• Passive PoE: 24-57V
• PoE: 802.3at/af

Environment requirements

• Operating Temperature: -40 – 75
• Storage Temperature: -40 – 75
• Operating Humidity: 5% – 95% non-condensing
• Storage Humidity: 5% – 95% non-condensing

Certificates FCC, CE
Accessories included

• IR04
• Power Adapter
• Detachable Wi-Fi Antennas
• Detachable Cellular Antennas
• 6-PIN Connector
• 10-PIN Connector
• 4-PIN Connector
• Ethernet Cable
• SIM Adapter KIT
• Mounting Kit
• Installation Guide

1994
Weight 4
Dimensions 129 × 114 × 50.6 mm
