Teltonika Industrial Gateway 1τμχ (TRB145)

Περιγραφή

TRB145 gateway

The TRB145 is a very small, lightweight, industrial LTE Cat 1 network interface with RS485 interface.

Thanks to its compact structure and easy installation, this device is perfect for solutions where one device needs to be remotely controlled via the RS485 interface.

Like other TRB products, TRB145 is intended for industrial use. It has many security features: SMS management, firewall, Open VPN, IPsec, Teltonika Networks remote management system (RMS) and FOTA support.

Model TRB145
Description TRB145 gateway The TRB145 is a very small, lightweight, industrial LTE Cat 1 network interface with RS485 interface. Thanks to its compact structure and easy installation, this device is perfect for solutions where one device needs to be remotely controlled via the RS485 interface. Like other TRB products, TRB145 is intended for industrial use. It has many security features: SMS management, firewall, Open VPN, IPsec, Teltonika Networks remote management system (RMS) and FOTA support.
3261
2463
719
717
3996
3994
4002
4000
4006
11116
4011
5125
4007
4005
4012
12910
3981
Antenna gain 2
Security

• Authentication: Pre-shared key, digital certificates, X.509 certificates
• Firewall: Pre-configured firewall rules can be enabled via the WebUI, unlimited firewall configuration via CLI; NAT; NAT-T
• Access control: Flexible access control of TCP, UDP, ICMP packets, MAC address filter

Management, monitoring, configuration

• Monitoring and management: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS, Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
• Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
• Modbus: TCP slave, TCP master, RTU master, RTU gateway, Modbus over MQTT
• Serial: Console, Over IP, Modem, NTRIP, Modbus

3990
4598
4597
18769
3987
Power supply 4 pin connector, 9-30 VDC
Software RutOS
Environment requirements

• Operating temperature: -40° C to 75° C
• Operating humidity: 10-90% non-condensing

Accessories included

• TRB145
• EU power supply
• LTE antenna (magnetic mounting, SMA male, 3 m cable)
• Micro-USB cable (0.8 m)
• Assembly key
• RS485 connector
• Quick start guide

3542
Weight 1
Dimensions 75 x 25 x 65 mm
Other features

• Network support: 4G/LTE (Cat 1), 3G, 2G
• CPU: Qualcomm, ARM Cortex A7, 1.2 GHz
• Memory: 512 MB Flash (70 MB free), 128 MB RAM (50 MB free)
• Status LED: 3x network type, 5x signal strength, 1x power
• Housing: Aluminum with the option of mounting on a DIN rail
• Degree of protection: IP30
• Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, DHCP, Telnet
