Teltonika TRB140 4G Ethernet Gateway

Περιγραφή

TRB140 gateway

The TRB140 is an ultra-small, lightweight, energy-efficient LTE Cat 4 industrial network interface with a Gigabit Ethernet port, digital I/O connectors and a micro-USB interface.

Thanks to its compact design, this product is perfect for projects and solutions where you only need to connect one device to a reliable Internet connection.

The TRB140 is specifically designed for use in the industrial sector and has a wide range of software security features such as SMS control, firewall, open VPN, IPsec, Remote Management System (RMS) and FOTA support.

Model TRB140
Description TRB140 gateway The TRB140 is an ultra-small, lightweight, energy-efficient LTE Cat 4 industrial network interface with a Gigabit Ethernet port, digital I/O connectors and a micro-USB interface. Thanks to its compact design, this product is perfect for projects and solutions where you only need to connect one device to a reliable Internet connection. The TRB140 is specifically designed for use in the industrial sector and has a wide range of software security features such as SMS control, firewall, open VPN, IPsec, Remote Management System (RMS) and FOTA support.
3261
2463
719
717
3996
3994
4002
4000
11116
4006
4007
5125
11115
4011
4008
4005
4012
12910
3981
Antenna gain 2
Security

• DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention)
• Firewall: Port forward, Traffic rules, Custom rules, Pre-configured firewall rules, DMZ, NAT, NAT-T, NAT helpers, Unlimited firewall configuration via CLI
• VPN: OpenVPN, IPsec, GRE, PPTP, L2TP

Management, monitoring, configuration

• Mobile functions: Auto APN, Band lock, SIM switch, Operator black/white list, Data/SMS limits
• Monitoring and management: WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS Ping Reboot, Wget reboot, Periodic Reboot, LCP and ICMP for link inspection
• Cloud solutions: RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
• SMS functions: SMS status, SMS configuration, Send/Read SMS via HTTP POST/GET, EMAIL to SMS, SMS to Email, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
• Services: DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Traffic Logging

3990
4597
3886
4598
3987
Power supply 4pin connector, 9-30 VDC
Software RutOS
Accessories included

• TRB140
• 4.5W power supply
• LTE antenna (magnet mounting, SMA male, 3m cable)
• Micro-USB cable (0.8 m)
• Assembly key
• LAN cable
• Quick start guide
• RMS leaflet

3542
Weight 1
Dimensions 75 x 25 x 65 mm
Environment requirements

• Operating temperature range: -40 °C to 75 °C
• Humidity during operation: 10 – 90% without condensation

Certificates

• CE/RED
• EAC
• RoHS
• WEEE

Other features

• Network support: 4G/LTE (Cat 4), 3G, 2G
• CPU: Qualcomm, ARM Cortex A7, 1.2 GHz
• Memory: 512 MB Flash (70 MB free), 128 MB RAM (50 MB free)
• Status LED: 3 x network type, 5 x signal strength, 2 x LAN, 1 x power
• Housing: Aluminum with the option of mounting on a DIN rail
• Degree of protection: IP30
• Network protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, DHCP, Telnet

25607
