Teltonika TRB246 LTE Cat 4 Gateway

Περιγραφή

TRB246 is an industrial 4G LTE gateway equipped with I/O, RS232, RS485 and Ethernet interfaces, designed for IoT solutions that require versatility and reliable M2M communication support. This gateway features dual SIM functionality and supports multiple protocols such as DNP3, DLMS and Modbus, which is crucial for ensuring smooth data transmission. Housed in an aluminum housing, this industrial IoT gateway is resistant to extreme environmental conditions in manufacturing, agriculture or construction.

Model TRB246
Description TRB246 is an industrial 4G LTE gateway equipped with I/O, RS232, RS485 and Ethernet interfaces, designed for IoT solutions that require versatility and reliable M2M communication support. This gateway features dual SIM functionality and supports multiple protocols such as DNP3, DLMS and Modbus, which is crucial for ensuring smooth data transmission. Housed in an aluminum housing, this industrial IoT gateway is resistant to extreme environmental conditions in manufacturing, agriculture or construction.
3261
2463
5125
4007
4006
4005
4008
4011
11115
4012
3287
3288
3893
3895
3959
12911
3981
Security

• Authentication: Pre-shared key, digital certificates, X.509 certificates, TACACS+, Radius, IP & Login attempts block
• Firewall: Pre-configured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T
• Attack prevention: DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
• VLAN: Tag-based VLAN separation
• Mobile quota control: Mobile data limit, customizable period, start time, warning limit, phone number
• WEB filter: Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only
• Access control: Flexible access control of SSH, Web interface, CLI and Telnet

Management, monitoring, configuration

• RMS: Teltonika Remote Management System (RMS)
• JSON-RPC: Management API over HTTP/HTTPS
• SNMP: SNMP (v1, v2, v3), SNMP Trap
• MQTT: MQTT Broker, MQTT publisher
• TR-069: OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
• Call: Reboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer
• SMS: SMS status, SMS configuration, send/read SMS via HTTP POST/GET
• SSH: SSH (v1, v2)
• FOTA: Firmware update from server, automatic notification
• WEB UI: HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log

3990
3876
3987
Power supply

• Input Voltage Range: 9-30 VDC, Reverse Polarity Protection
• Power Consumption: Idle: < 1.5 W, Max: < 3.5 W

Certificates

• CE,
• UKCA,
• RCM,
• CB,
• EAC,
• UCRF,
• WEEE

Environment requirements

• Operating temperature: -40°C to 75°C
• Operating humidity: 10% to 90% non-condensing
• Ingress protection: IP30

1994
Weight 1
Dimensions 83 x 25 x 74.2 mm
