TP-LINK SG3210X-M2 v1 Managed L2 PoE+ Switch με 8 Θύρες Ethernet και 2 SFP Θύρες

Περιγραφή

• 2.5Gbps Speeds: 8 x 2.5Gbps RJ45 ports provide fast and reliable connections to other switches and devices.
• 10G Lightning Fast Uplink: 2 x 10Gbps SFP+ slots provide high-bandwidth connectivity and non-blocking switching capabilities.
• Integrated with Omada SDN: Zero-Touch Provisioning (ZTP), centralized cloud management, and intelligent monitoring.
• Centralized Management: Cloud access and Omada App for exceptional convenience and easy management.
• Static Routing: Helps direct internal traffic for more efficient use of network resources.
• Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP Snooping.
• Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image provide powerful management capabilities.

Description

• 2.5Gbps Speeds: 8 x 2.5Gbps RJ45 ports provide fast and reliable connections to other switches and devices.
• 10G Lightning Fast Uplink: 2 x 10Gbps SFP+ slots provide high-bandwidth connectivity and non-blocking switching capabilities.
• Integrated with Omada SDN: Zero-Touch Provisioning (ZTP), centralized cloud management, and intelligent monitoring.
• Centralized Management: Cloud access and Omada App for exceptional convenience and easy management.
• Static Routing: Helps direct internal traffic for more efficient use of network resources.
• Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP Snooping.
• Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image provide powerful management capabilities.

1212
1214
4775
1223
1224
1222
1217
1234
1239
21360
1271
1255
4980
1251
1247
4760
23336
11459
1267
Throughput 8
Forwarding rate 5
MAC address table size 1
1221
Jumbo frame size 9
1264
VLAN

• VLAN Group: Max 4K VLAN Groups
• 802.1Q Tagged VLAN
• MAC VLAN: 256 Entries
• Protocol VLAN: Protocol Template 16, Protocol VLAN 16
• GVRP
• VLAN VPN (QinQ): Port-Based QinQ; Selective QinQ
• Voice VLAN

QoS

• 8 priority queues
• 802.1p CoS/DSCP priority
• Queue scheduling: SP (Strict Priority); WRR (Weighted Round Robin);SP+WRR
• Bandwidth Control: Port/Flow based Rating Limiting
• Smoother Performance
• Action for Flows: Mirror (to supported interface); Redirect (to supported interface); Rate Limit; QoS Remark

Security

• Secure web management through HTTPS with SSLv3/TLS 1.2
• Secure Command Line Interface (CLI) management with SSHv1/SSHv2
• IP/Port/MAC based access control

L2 features

• IGMP Snooping: IGMP v1/v2/v3 Snooping; Fast Leave; IGMP Snooping Querier; IGMP Authentication; IGMP Authentication
• MLD Snooping: MLD v1/v2 Snooping: Fast Leave; MLD Snooping Querier; Static Group Config; Limited IP Multicast
• MVR
• Multicast Filtering: 256 profiles and 16 entries per profile

L3 features

• 32 IPv4/IPv6 Interfaces
• Static Routing: 48 static routes
• Static ARP: 128 Static Entries
• Proxy ARP
• Gratuitous ARP
• DHCP Server
• DHCP Relay: DHCP Interface Relay' DHCP VLAN Relay
• DHCP L2 Relay

2638
1229
1228
Power consumption 1
Environment requirements

• Operating Temperature: 0-50 degrees Celsius
• Storage Temperature: -40-70 degrees Celsius
• Operating Humidity: 10-90% RH non-condensing
• Storage Humidity: 5-90% RH non-condensing

Certificates CE, FCC, RoHS
Power supply 100-240 V AC~50/60 Hz
Dimensions 294 × 180 × 44 mm
25607
