Περιγραφή
- AMD Socket AM5Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors
- Digital twin 16+2+2 phases VRM solution
- Dual Channel DDR54*DIMMs with AMD EXPO Memory Module Support
- WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
- EZ-Latch PlusPCIe and M.2 slots with Quick Release & Screwless Design
- EZ-Latch ClickM.2 heatsinks with screwless design
- Sensor Panel LinkOnboard video port for hassle-free in-chassis panel setup
- Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
- Ultra-Fast Storage4*M.2 slots, including 3* PCIe 5.0 x4
- Efficient ThermalVRM Thermal Armor Advanced & M.2 Thermal Guard L
- Fast Networking2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
- Extended ConnectivityDual USB4 Type-C with DP-Alt, HDMI
- Reliable AudioRealtek ALC1220 HD Audio & Audiophile Grade Capacitors
- Ultra Durable PCIe Armor : The metal back plate of PCIe x16 slot for enhanced durability
- PCIe UD Slot X PCIe 5.0 x16 slot with 10X strength for graphics card
Description
- AMD Socket AM5Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors
- Digital twin 16+2+2 phases VRM solution
- Dual Channel DDR54*DIMMs with AMD EXPO Memory Module Support
- WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
- EZ-Latch PlusPCIe and M.2 slots with Quick Release & Screwless Design
- EZ-Latch ClickM.2 heatsinks with screwless design
- Sensor Panel LinkOnboard video port for hassle-free in-chassis panel setup
- Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
- Ultra-Fast Storage4*M.2 slots, including 3* PCIe 5.0 x4
- Efficient ThermalVRM Thermal Armor Advanced & M.2 Thermal Guard L
- Fast Networking2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
- Extended ConnectivityDual USB4 Type-C with DP-Alt, HDMI
- Reliable AudioRealtek ALC1220 HD Audio & Audiophile Grade Capacitors
- Ultra Durable PCIe Armor : The metal back plate of PCIe x16 slot for enhanced durability
- PCIe UD Slot X PCIe 5.0 x16 slot with 10X strength for graphics card
Model X870 A ELITE WF7 ICE
22862
15632
16025
19464
17383
638
587
Chipset type AMD X870
4403
22020
22815
23081
23086
22643
22632
23118
23079
17035
19476
21989
22013
22015
23080
23114
23117
Max memory size 2
19491
7965
7974
11530
Max. number of SATA devices 4
635
Detailed data on disk/drive interfaces Expansion Slots1 PCI Express x16 (PCIEX16) slot, integrated with the processor:AMD Ryzen 9000/7000 series processors support PCIe 5.0 x16 mode* M2B_CPU and M2C_CPU slots share bandwidth with PCIEX16 slot.When M2B_CPU or M2C_CPU slot is occupied, PCIEX16 slot operates at up to x8 mode.AMD Ryzen 8000 Series-Phoenix 1 processors support PCIe 4.0 x8 modeAMD Ryzen 8000 Series-Phoenix 2 processors support PCIe 4.0 x4 mode(The PCIEX16 slot only supports a graphics card or NVMe SSD. If you only want to install one graphics card, you must install it in the PCIEX16 slot.)Chipset:- 1 PCI Express x16 slot, supporting PCIe 4.0 and operating at x4 mode (PCIEX4)* The PCIEX4 slot shares bandwidth with the M2D_SB connector. The PCIEX4 slot becomes unavailable when a device is installed in the M2D_SB connector.- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x2 speed (PCIEX2)Storage Interface1 x M.2 connector (M2A_CPU), integrated with the processor, supporting socket 3, M key, type 25110/22110/2580/2280 SSD:AMD Ryzen 9000/7000 series processors support PCIe 5.0 x4/x2 SSDsAMD Ryzen 8000-Phoenix 1 series processors support PCIe 4.0 x4/x2 SSDsAMD Ryzen 8000-Phoenix 2 series processors support PCIe 4.0 x4/x2 SSDs2 x M.2 connectors (M2B_CPU, M2C_CPU), integrated with the processor, supporting socket 3, M key, type 22110/2280 SSDs:AMD Ryzen 9000/7000 series processors support PCIe 5.0 x4/x2 SSDs* M2B_CPU and M2C_CPU connectors become unavailable when AMD Ryzen 8000-Phoenix 1/Phoenix 2 series processors are used.1 x M.2 connector (M2D_SB), integrated into the chipset, supporting Socket 3, M-Key, Type 22110/2280 PCIe 4.0 x4/x2 SSD4 x SATA 6Gb/s connectors Supports RAID 0, RAID 1, RAID 5, and RAID 10 for NVMe SSD storage devices* RAID 5 is only available on AMD Ryzen 9000 series processors.Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices
Graphics Integrated graphics processor with AMD Radeon Graphics support + ASMedia USB4 controller:- 2 x USB4 USB Type-C ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840×2160@240 Hz* Support DisplayPort version 1.4 and HDR.Integrated graphics processor with AMD Radeon Graphics support:- 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz* Support HDMI version 2.1, HDCP 2.3 and HDR.** Support native HDMI 2.1 TMDS compliant ports.- 1 x front HDMI port, supporting a maximum resolution of 1920×1080@30 Hz* Support HDMI version 1.4(Graphics specifications may vary depending on processor support.) Support for up to four displays simultaneously.
Sound card CODE Realtek ALC1220* The line-out jack on the rear panel supports DSD audio.High-resolution audio2/4/5.1/7.1-channel* The audio jack functionality can be changed via audio software. To configure 7.1-channel audio, you must access the audio software for audio settings.S/PDIF output support
18721
19467
927
Network interface LANRealtek 2.5GbE LAN chip (2.5Gbps/1Gbps/100Mbps)Wireless Communication moduleMediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.4
- Support for 11be 160MHz wireless standard
Realtek Wi-Fi 7 RTL8922AE (PCB rev. 1.1)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.4
- Support for 11be 160MHz wireless standard
USB ports at back panel 1
USB ports on motherboard 7
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 3
646
389
391
5237
5245
5248
7840
24369
11056
5243
5236
20026
7486
7490
7768
7492
7487
7769
19614
25332
7793
23426
12168
7474
20067
7792
7481
7499
7475
23176
24780
15634
25331
23174
23202
Special functions
- GIGABYTE Control Center (GCC) Support
- * The available applications in GCC may vary depending on the motherboard model. The supported functions of each application may also vary depending on the motherboard specifications.
- Q-Flash Support
- Q-Flash Plus Support
- Smart Backup Support
BIOS
- 1 x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
648
Dimensions 30.5 cm x 24.4 cm
22012
Software
- Norton Internet Security (OEM version)
- LAN bandwidth management software
25607
