Περιγραφή
TUF GAMING Z890-PRO WIFI
The ASUS TUF GAMING Z890-PRO WIFI leverages all the essential elements of the latest Intel Core Ultra (2 Series) processors and combines them with game-ready features and proven durability. Designed with military-grade components, an enhanced power solution, and a comprehensive cooling system, this motherboard exceeds expectations with solid, stable performance for marathon gaming sessions. TUF GAMING motherboards also undergo rigorous durability testing to ensure they can handle conditions where others might fail. This platform delivers the power and connectivity that advanced AI computing applications demand.
Description TUF GAMING Z890-PRO WIFIThe ASUS TUF GAMING Z890-PRO WIFI leverages all the essential elements of the latest Intel Core Ultra (2 Series) processors and combines them with game-ready features and proven durability. Designed with military-grade components, an enhanced power solution, and a comprehensive cooling system, this motherboard exceeds expectations with solid, stable performance for marathon gaming sessions. TUF GAMING motherboards also undergo rigorous durability testing to ensure they can handle conditions where others might fail. This platform delivers the power and connectivity that advanced AI computing applications demand.
Model TUF GAMING Z890-PRO WIFI
25175
24470
637
586
Chipset type Intel Z890 Chipset
4403
22020
25302
Max memory size 1
19531
20069
19491
22890
25010
Max. number of SATA devices 4
635
Detailed data on disk/drive interfaces
- Supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*
- Intel Core Ultra Processors(series 2)*
- M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
- M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
- Intel Z890 Chipset
- M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
- M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
- 4 x SATA 6Gb/s ports
- * Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only support RAID 0/1/5.
Graphics
- 1 x DisplayPort**
- 1 x HDMI port***
- 2 x Intel Thunderbolt 4 (USB Type-C) ports support DisplayPort and Thunderbolt video output****
* Graphics specifications may vary depending on processor type. For updates, please visit www.intel.com.** Supports up to 4K@60Hz as per DisplayPort 1.4 specification.*** Supports 4K@60Hz as per HDMI 2.1 specification.**** Supports up to 8K@60Hz x1 with DSC or 4K@60Hz x2, maximum total bandwidth up to 23.8 Gbps or 16 Gbps/16 Gbps. For supported resolutions, see DisplayPort 2.1 specification.***** VGA resolution support depends on processor or graphics card resolutions.
Sound card Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*- Impedance sensing for front and rear headphone outputs- Internal audio amplifier to enhance premium sound quality for headphones and speakers- Supports: jack detection, streaming, and front panel jack repurposing- High-quality stereo playback output SNR 120 dB and recording input SNR 113 dB (line-in)- Supports playback up to 32-bit/192 kHz*Audio Features- Audio Shielding- Rear Optical S/PDIF Output Port- Premium Audio Capacitors- Dedicated PCB Audio Layers- Audio Cover- Unique De-Pop Circuit* Due to HDA bandwidth limitations, 32-bit/192 kHz is not supported for 7.1 Surround Sound.
24058
927
18721
Network interface Ethernet
- 1 x Intel 2.5Gb Ethernet
- TUF LANGuard
Wireless and Bluetooth
- Wi-Fi 7*
- 2×2 Wi-Fi 7 (802.11be)
- Supports 2.4/5/6 GHz frequency bands**
- Supports Wi-Fi 7 160 MHz band, up to 2.9 Gbps transfer speeds.
- Bluetooth v5.4***
*Wi-Fi features may vary by operating system.For Windows 11, Wi-Fi 7 will require version 24H2 or later for full functionality. Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E.For Windows 10, please note that there is no driver available; please refer to the Wi-Fi chipset vendor's website for details.**6 GHz Wi-Fi frequency band and bandwidth regulations may vary by country. ***Bluetooth version may vary; please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USB ports at back panel 8
USB ports on motherboard 7
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 1
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports 9
646
390
391
5237
5243
11707
5251
5250
5236
5252
5253
5239
5241
24987
10607
21971
19614
7487
7475
7481
7499
7486
7484
7795
20067
7792
7794
7793
19599
12168
7474
23202
7491
7490
10609
Special functions ASUS TUF PROTECTION- DIGI+ VRM (- Digital power design with DrMOS)- ESD Guards – TUF LANGuard- Overvoltage protection- SafeSlot- Stainless-steel back I/OASUS Q-Design – M.2 Q-Latch- M.2 Q-Release- M.2 Q-Slide- Q-Release Slim (with PCIe SafeSlot)- Q-Antenna- Q-Dashboard- Q-DIMM- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])- Q-SlotASUS Thermal Solution- M.2 heatsink backplate- M.2 heatsink- VRM heatsink designASUS EZ DIY- BIOS FlashBack button- BIOS FlashBack LED- CPU Socket lever protector- ProCool- Pre-mounted I/O shield- SafeDIMMAura Sync- Addressable Gen 2 headersFront Panel USB 20Gbps with PD Fast Charge Support- Support: up to 30W fast charging and USB Wattage Watcher- Output: 5V/9V max. 3A, 12V max 2.5A, 15V max. 2.0A- Compatible with PD3.0
BIOS 256 Mb Flash ROM, UEFI AMI BIOS
648
Dimensions 30.5 cm x 24.4 cm
Accessories included
- 2 x SATA 6Gb/s Cable
- ASUS WiFi Q-Antenna
- M.2 Q-Slide Pack
- 2 x M.2 Rubber Pack
- M.2 SSD Screw Pack
- TUF GAMING Sticker
- Quick Start Guide
22012
Software ASUS Exclusive SoftwareArmoury Crate- Aura Creator- Aura Sync- Fan Xpert 4 (with AI Cooling II)- Power SavingASUS DriverHubASUS GlideXUSB Wattage WatcherTurboV Core TUF GAMING CPU-ZDTS Audio ProcessingNorton 360 for Gamers (60 Days Free Trial)WinRAR (40 Days Free Trial)UEFI BIOSAI Overclocking GuideASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ Mode- ASUS MyHotkeyFlexKeyNPU Boost
25607
