Motherboard B650M GAMING WIFI6E 2DDR5 HDMI/DSub M2 m.ATX

Περιγραφή

• AMD AM5 Socket: Supports AMD Ryzen 7000/Ryzen 8000/Ryzen 9000 Series Processors
• Unmatched Performance: 5+2+2 Phase Digital VRM
• Dual-Channel DDR5 Memory: 2 SMD DIMMs with AMD EXPO and Intel XMP Memory Support
• Super-Fast Storage: PCIe 4.0 x4 M.2 Connector
• EZ-Latch: PCIe x16 Slot with Quick-Release Design
• High-Speed Networking: 2.5GbE LAN and 802.11ax Wi-Fi 6
• Expanded Connectivity: HDMI, D-Sub
• Smart Fan 6: Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
• Q-Flash Plus: BIOS Update without Installing the CPU, Memory, and Graphics Card

Description

• AMD AM5 Socket: Supports AMD Ryzen 7000/Ryzen 8000/Ryzen 9000 Series Processors
• Unmatched Performance: 5+2+2 Phase Digital VRM
• Dual-Channel DDR5 Memory: 2 SMD DIMMs with AMD EXPO and Intel XMP Memory Support
• Super-Fast Storage: PCIe 4.0 x4 M.2 Connector
• EZ-Latch: PCIe x16 Slot with Quick-Release Design
• High-Speed Networking: 2.5GbE LAN and 802.11ax Wi-Fi 6
• Expanded Connectivity: HDMI, D-Sub
• Smart Fan 6: Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
• Q-Flash Plus: BIOS Update without Installing the CPU, Memory, and Graphics Card

Model B650M GAMING WIFI6E
22862
17383
16025
15632
19464
637
587
Chipset type AMD B650
4403
22018
17035
23086
23081
23079
22632
21989
22015
22815
22643
22013
19476
Max memory size 1
7965
12363
11530
Max. number of SATA devices 4
635
Detailed data on disk/drive interfaces 1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSD:    AMD Ryzen 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs    AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs    AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs    4 złącza SATA 6Gb/sRAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devicesRAID 0, RAID 1, and RAID 10 support for SATA storage devices
Graphics Integrated Graphics Processor – AMD Radeon Graphics support

• 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz
• 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz


Sound card

• Realtek audio codec
• Obsługa High Definition Audio
• Ilość kanałów audio 2/4/5.1/7.1


19467
927
18721
Network interface LAN

• Realtek 2.5GbE LAN chip (2.5Gbps/1Gbps/100Mbps)

Realtek Wi-Fi 6E RTL8852CE wireless communication module

• WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
• BLUETOOTH 5.3
• Support for 11ax 160MHz wireless

USB ports at back panel 6
USB ports on motherboard 3
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports 3
646
389
391
5237
20026
25434
7788
5245
5239
5251
5241
5236
5234
23207
7487
7486
7490
23174
7475
7764
7494
7474
7786
7792
7481
25442
7492
Special functions

• Support for GIGABYTE Control Center (GCC)
• Q-Flash support
• Support for Q-Flash Plus

BIOS

• 1 x 256 Mbit flash
• Use of licensed AMI UEFI BIOS
• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0


649
Dimensions 24 x 22.5 cm
9594
22012
Software

• Norton Internet Security (wersja OEM)
• LAN bandwidth management software
